UHF Antenna System - C3S

Main Features:

  • Curved cross section tape
  • Near omnidirectional radiation pattern
  • Antenna - Stainless spring steel
  • 1-2.0 second opening time (from -70°C to +85°C)
  • Cold redundant system
  • ESA qualified concept
  • Easy to tune
  • Antenna configuration: V-dipole
Specifications
Center Frequency:
401 MHz
Input impedance (deployed):
50 Ω
Plarization:
Linear
Input port:
Coaxial
Connector:
MCX female
Bandwidth:
30 MHz
Maximum input power:
3 Watt
Antenna Gain:
3.8 dBi
Mass:
200 g
Dimensions:
18 x 100 x 100 mm
Antenna Length:
180 mm
Operational Temperature Range:
-70C to 85C
