CubeSat Kit™ Chassis Walls

Precision constructed from Al 5052-H32 and plated according to the CubeSat Design Specification (CDS), the Chassis Walls is the primary structural element in a CubeSat Kit™ structure. One-piece, extremely strong and light, each one offers a 97mm x 97mm internal cross-sectional volume in which you place and secure your nanosatellite's bus and payload modules. Solid-wall and skeletonized versions are available from stock.

Chassis Walls must be combined with a Base Plate Assembly and a Cover Plate Assembly in order to create a complete CubeSat Kit structure. End Hinged deployable solar arrays can attach to Base or Cover Plate assemblies.

Pro Chassis Walls accomodate for Side Hinged and Wrap Around solar panel arrays. See details in PMDSAS design guideline PDF.

Internal Volume:
97 X 97 mm (Cross-Section)
AL 5052-H32
Flight Hardware
