Celeste – the GNSS Receiver

Spacemanic's Celeste – the GNSS Receiver – is a state-of-the-art multi-GNSS receiver module designed specifically for nanosatellite position acquisition and determination. Its robust, plug&play design ensures seamless integration with a wide variety of CubeSat components, making it an ideal choice for space missions. The Celeste receiver is capable of utilizing multiple global navigation satellite systems, such as GPS, BeiDou, and Galileo, ensuring reliable and accurate positioning data across different regions and conditions.

Features:

  • Plug&Play design
  • Compatible with Spacemanic cubesat standard
  • Compatible with cubesat components from other vendors
  • Robust design
  • GPS/ GLONASS/BeiDou/Galileo
  • Cubesat Space Protocol compatible
  • Works directly with active or passive antenna
  • New updated version from 2022
Specifications
Dimensions:
67 x 42 x 7 mm
Mass:
25 g
Power Consumption:
250 mW
Supply Voltage:
3.3 V
Supply Voltage:
5 V
Operating Temperature Range:
-40C to 85C
Protocol:
Cubsat Space Protocol
Interface:
I2C
Interface:
RS485
Interface:
CAN
Interface:
UART
Interface:
PPS output
