SSA02 - 34dB Wide Bandwidth Amplified S-Band Patch Antenna

The EXA SSA02 is the power-amplified version of the SSA01 wide bandwidth S-band antenna than can accommodate a bandwidth of up to 195 MHz for missions that need greater speed and/or bandwidth separation capabilities and great flexibility on the final frequencies’ selection. It will work between 2025 and 2120 MHz and 2200 and 2300 MHz without sacrificing gain, allowing your mission to not wait for the final bands and frequencies approval: By the time you get your approval papers from your telecommunications authority, you will be ready to fly, just request a frequency within SSA02’s ample range and you save at least 6 months of red tape time.

SSA02 gives your mission’s link budget a powerful boost thanks to its onboard amplifier tied directly to the antenna, working alongside a RF switch chip that allows safe transceiver capability to your radio; the total ERP delivered by the SSA02 is a powerful 34 dB allowing the use of very low power radios, thus saving power without sacrificing link budget.

This also means that 2 radios can share the same antenna.

Features:

  • Flight heritage since 2020
  • Wide bandwidth: 2025 to 2120 MHz and 2200 to 2300 MHz
  • Powerful 34 dB of ERP
  • Only 4.8mm thickness
  • On board RF-switch allows safe transceiver capability
  • Allows 2 radios to operate de same antenna
  • Allows the use of very low power radios
  • Custom configurable choice of connectors and/or cables
  • Wide FOV of 120 degrees
  • Designed for LEO missions and requirements
  • Manufactured according to NASA and ESA space standards and materials
  • Functional, performance, thermal bake out and vibration tests provided with documentation.
  • Compatible and compliant with standard deployers and CubeSat Standard
Specifications
Frequency Range:
2025 to 2120 MHz
Frequency Range:
2200 to 2300 MHz
Total Effective Radiated Power:
34 dB
Thickness:
4.8 mm
Field of View:
120 degrees
Total Bandwidth:
195 MHz
Power Amplifier Gain:
24 dB
Mass:
60 g
Dimensions:
97 x 80 x 4.8 mm
Operating Temperature Range:
-40C to 85C
Radiation Tolerance:
>4 years in LEO
