nD3PP nano Pin Puller - Dcubed - SmallSat Catalog - Orbital Transports
Additional Information
Dimensions:
17 x 17 x 17 mm
Mass:
12 grams (Aluminum-Titanium) or 25 grams (Stainless Steel)
Operating Temperature Range:
-65C to 75C
Shear Load:
>50 N
Documentation

Compact, linear actuator with space heritage providing a smooth and reliable trigger on orbit.

The Dcubed Nano Pin Puller (nD3PP), available in Stainless Steel or Aluminum-Titanium, is a Shape Memory Alloy (SMA) based release actuator which locks sensitive equipment during launch and safely releases it on orbit. It is one of the smallest, yet powerful space-qualified Hold-Down and Release Mechanism (HDRM) solutions on the market. Moreover, it is easily field-resettable, easy-to-use, and readily available as a COTS part.

VIDEO: Check out how to trigger and easily reset the Dcubed Nano Pin Puller nD3PP here:

Key Features

  • Front and Rear Field Resettable in Seconds, up to 400 times
  • Short Delivery Time (6-8 weeks)
  • Fully Redundant Actuation
  • Space Heritage (TRL 9)
  • Smart SMA Trigger
  • Ultra Low Shock
  • Actuation Sensor
  • Shear Load (Release Load) >50 N
  • Proof Load: 85 N Push-in Load, 300 N Sideload
  • Body Size: 17 x 17 x 17 mm
  • Mass: 12 grams (Aluminum-Titanium) or 25 grams (Stainless Steel)
  • Temperatures: -65°C to +75°C
  • Customizable Interfaces

Export Control

  • The Dcubed Nano Pin Puller (nD3PP) is ITAR Free.
Submit an inquiry in order to request documents related to this product (Datasheet(s), CAD, ...etc).

See contact form here

Nano Pin Puller (nD3PP)

Dcubed
Description

Compact, linear actuator with space heritage providing a smooth and reliable trigger on orbit.

The Dcubed Nano Pin Puller (nD3PP), available in Stainless Steel or Aluminum-Titanium, is a Shape Memory Alloy (SMA) based release actuator which locks sensitive equipment during launch and safely releases it on orbit. It is one of the smallest, yet powerful space-qualified Hold-Down and Release Mechanism (HDRM) solutions on the market. Moreover, it is easily field-resettable, easy-to-use, and readily available as a COTS part.

VIDEO: Check out how to trigger and easily reset the Dcubed Nano Pin Puller nD3PP here:

Key Features

  • Front and Rear Field Resettable in Seconds, up to 400 times
  • Short Delivery Time (6-8 weeks)
  • Fully Redundant Actuation
  • Space Heritage (TRL 9)
  • Smart SMA Trigger
  • Ultra Low Shock
  • Actuation Sensor
  • Shear Load (Release Load) >50 N
  • Proof Load: 85 N Push-in Load, 300 N Sideload
  • Body Size: 17 x 17 x 17 mm
  • Mass: 12 grams (Aluminum-Titanium) or 25 grams (Stainless Steel)
  • Temperatures: -65°C to +75°C
  • Customizable Interfaces

Export Control

  • The Dcubed Nano Pin Puller (nD3PP) is ITAR Free.
Submit an inquiry in order to request documents related to this product (Datasheet(s), CAD, ...etc).

See contact form here

Current Stock:
Adding to request… The item has been added
Add this to a request to access pricing information and additional technical data. After submission, get a response within 3 business days.
