MICRO R3 - ENPULSION - SmallSat Catalog - Orbital Transports

MICRO R3

Building on the heritage of the ENPULSION NANO, the ENPULSION MICRO R3 is a scaled version of the technology to target small and medium size spacecrafts. It is engineered in a modular approach, with units clustering easily together to form building blocks that can be arranged for various mission profiles. First ENPULSION MICRO R3 thrusters were delivered to customers in the end of 2020.

ENPULSION MICRO R3 TABLE comparison

Specifications
Type:
Electric Propulsion
Nominal Thrust:
1 mN (1 unit)
Nominal Thurst:
4 mN (4 units)
Dynamic Thrust Range:
200 µN to 1.35 mN (1 unit)
Dynamic Thrust Range:
200 µN to 5.4 mN (1 unit)
Specific Impulse:
1,500 to 6,000 s
Maximum Power Consumption:
120 W (1 unit)
Maximum Power Consumption:
480 W (4 units)
Dimensions:
140 x 120 x 98.6 mm (1 unit)
Dimensions:
140 x 120 x 34.0 mm (PPU box; 1 per unit)
Dry Mass:
2.6 kg (per unit)
Wet Mass:
3.9 kg (per unit)
Propellant Mass:
1.3 kg (per unit)
