The Anywaves Ka-Band TT&C Antenna is a compact, reliable solution for telemetry, tracking and command operations in the Ka-band. Available in three dedicated models — Rx (29.5–30 GHz), Tx (19.7–20.2 GHz), and Rx/Tx (17.7–20.2 GHz and 27.5-30.0 GHz) — it provides hemispherical beam coverage (HPBW > 90°) with excellent axial ratio stability and a reflection coefficient better than −18 dB across the full frequency band.
Its choke ring design minimises multipath interference, while the full metal construction ensures resilience in the most demanding space environments. Supporting single or dual-circular polarization (RHCP/LHCP), scalable in frequency, and compatible with the Anywaves Test Hat, it offers the flexibility required by modern satellite platforms. Lightweight, ITAR Free, and supplied with full acceptance testing on flight models.
Key Features:
-
- Full duplex Tx & Rx — separate or combined apertures
- Hemispherical coverage HPBW > 90°
- Full metal design — no radome degradation
- Test Hat compatible
- Full acceptance testing included
- ITAR Free — worldwide delivery
Included Services
-
- Complete EIDP (End Item Data Package)
- In-Depth Engineering Support
- Further Testing Available On Demand
- Specific Requests Analysis With Experts
| Parameter | Value |
|---|---|
| Lead Time | 6 to 12 months (contact us for shorter lead time) |
| Envelope size | (Rx) 108 × 108 × 44 mm |
| Envelope size | (Tx) 150 × 150 × 60 mm |
| Envelope size | (Rx/Tx) 90 × 90 × 40 mm |
| Frequency band | Rx: 29.5–30 GHz |
| Frequency band | Tx: 19.7–20.2 GHz |
| Mass | Rx: < 75 g |
| Mass | Tx: < 140 g |
| Mass | Rx/Tx : < 80 g |
| Realized gain | Rx: > 5 dBi @ boresight | > 0 dBi @ ±80° |
| Realized gain | Tx: > 3 dBi @ boresight | > 0 dBi @ ±80° |
| Realized gain | Rx/Tx: – Tx band: > 4 dBi @ boresight | > 0 dBi @ ±67° – Rx band: > 8 dBi @ boresight | > 0 dBi @ ±60° |
