X-Band Patch Antenna - EnduroSat - SmallSat Catalog - Orbital Transports
Additional Information
Frequency Range:
8025 to 8400 MHz
RF Output Power:
up to 4 W
Mass:
2.20 g (+/- 0.05g)
Polarization:
Right Hand Circular
Half Power Beam Width:
74 deg
Gain:
above 6 dBi
Documentation

EnduroSat's X-band Patch Antenna is a high gain right hand circularly polarized antenna. Its extremely low mass and very small form-factor make it easily integrated on any side of a CubeSat structure compliant with the CubeSat standard.

Includes:

  • Packed in a custom box
  • 5 hours of engineering support
  • Full warranty
  • Technical information (Datasheet)

Qualification:

Space qualification tests are performed on the Qualification Engineering Model. Qualification test levels and duration will follow the ESA standard ECSS-E-ST-10-03C and GEVS: GSFC-STD-7000A.

X-Band Single Patch Antenna

EnduroSat
Description

EnduroSat's X-band Patch Antenna is a high gain right hand circularly polarized antenna. Its extremely low mass and very small form-factor make it easily integrated on any side of a CubeSat structure compliant with the CubeSat standard.

Includes:

  • Packed in a custom box
  • 5 hours of engineering support
  • Full warranty
  • Technical information (Datasheet)

Qualification:

Space qualification tests are performed on the Qualification Engineering Model. Qualification test levels and duration will follow the ESA standard ECSS-E-ST-10-03C and GEVS: GSFC-STD-7000A.

Current Stock:
Adding to request… The item has been added
Add this to a request to access pricing information and additional technical data. After submission, get a response within 3 business days.
