6U Thermal Vacuum System
Rydberg Vacuum SciencesRVS knows that Thermal Vacuum Testing is the last thing you want to worry about as your launch date approaches. Our line of small satellite test systems can provide you with drop-in-place test solutions for compliance with GSFC-STD-7000 or MIL-STD-1540 test standards. We take the guesswork out of Thermal Vacuum Testing to ensure you’ll be ready for orbit.
Standard Features
- 6U Test Volume (370mm x 240mm x 120mm)
- Fast 300 L/s turbomolecular pump backed by a frame-integrated dry roots pump
- Temperature controlled platen with 50mm x 50mm M6 grid for UUT fixturing and integrated thermal radiation shielding
- Two blank ISO-100LF user ports for passthrough of electrical, instrumentation, or gasses as needed
- Six user type-T thermocouple jacks
- Low utility requirements: 120V/15A/1ph and compressed air, no cooling water required
- Modbus-TCP based DAQ allows for easy integration with existing SCADA systems
- Available accessories include:
- RGA (100amu-300amu)
- TQCM
- Optical Witness Sample Holder
- Two years of annual on-site maintenance and servicing
- Easy Installation with small footprint
- User Friendly Interface
- Standard systems ship in 8-10 weeks
- Have a short term testing need? Weekly or monthly rental units available
- Lead Time:
- Ships in 8 to 10 weeks
- Cubic Test Volume:
- 370 x 240 x 120 mm (6U)
- Chamber Dimensions:
- 500 mm Length x 300 mm Diameter
- Temperature Range (6UB):
- ambient to 150C
- Temperature Range (6UC):
- -150C to 150C
- Average Ramp Rate:
- 3 Celcius/min
- Platen Grid (M6):
- 50 x 50 mm
- Temperature measurement:
- (6) Type-T Thermocouple input
- Thermocouple Accuracy:
- +/- 0.1% FSR
- Radiation Shielding:
- Standard
- High Vacuum Pump:
- Hybrid Turbomolecular Pump
- Turbopump Speed:
- 300 L/s (Nitrogen)
- Rough Vacuum Pump Type:
- Dry Roots
- Rough Pump Speed:
- 110 L/min
- Typical Pumpdown Time:
- 15 to 20 minutes (Atmospheric to 5x10^-5 Torr)
- Ultimate Pressure:
- 8 x 10^-7 Torr
- Open User Ports:
- (2) x ISO 100 LF
- User Interface:
- 7in. Color Touchscreen, TCP/IP
- Data Storage:
- Internal 32GB, USB, Ethernet
- Integrated Remote VPN:
- Standard
- Compressed Air:
- 5 to 7 bar (60 to 100 psi)
- Air/GN2/Exhaust Connections:
- 8mm (5/16in.) Push-To-Connect Tube Fittings
- LN2 Connection (6UC):
- CGA295
- Power Requirements:
- 120V/15A/1ph
- Warranty:
- 2 Years
- 6U Test Volume (370mm x 240mm x 120mm)
- Fast 300 L/s turbomolecular pump backed by a frame-integrated dry roots pump
- Temperature controlled platen with 50mm x 50mm M6 grid for UUT fixturing and integrated thermal radiation shielding
- Two blank ISO-100LF user ports for passthrough of electrical, instrumentation, or gasses as needed
- Six user type-T thermocouple jacks
- Low utility requirements: 120V/15A/1ph and compressed air, no cooling water required
- Modbus-TCP based DAQ allows for easy integration with existing SCADA systems
- Available accessories include:
- RGA (100amu-300amu)
- TQCM
- Optical Witness Sample Holder
- Two years of annual on-site maintenance and servicing
- Easy Installation with small footprint
- User Friendly Interface
- Standard systems ship in 8-10 weeks
- Have a short term testing need? Weekly or monthly rental units available
