X-band Transmitter

EnduroSat's X-band transmitter features impressive high data rate (150 Mbps+). It is fully DVB-S2/S2X and CCSDS compliant. The X-band transmitter supports variety of data interfaces and modulation schemes. Fully compliant with the CubeSat standard.

Includes:

  • Packed in a custom box
  • 5 hours of engineering support
  • Full warranty
  • Technical information (Datasheet)

Qualification

Space qualification tests will be performed on the Qualification Engineering Model. Qualification test levels and duration will follow the ESA standard ECSS-E-ST-10-03C and GEVS: GSFC-STD-7000A.

Specifications
Frequency Range:
8025 - 8400 MHz
Maximum Transmit Power:
2 W
Transmit Data Rate in LEO:
up to 150 Mbps
SFDR:
>60 dBc
Power Supply:
12 V
Power Consumption during Tx:
up to 12 W
Interface:
LVDS
Interface:
SPI
Interface:
CAN
Interface:
I2C
Compliance:
DVB-S2
Compliance:
CCSDS
