Additional Information
Lead Time:
12 weeks
Beam Size:
25 mm diameter
Beam Homogeneity:
> 90%
Light Collumation:
< 10 degree
Lightspectrum:
450 - 1100 nm
Optical head temperature range:
-50C to 100C (no vacuum)
Optical head temperature range:
-40C to 80C (vacuum)
Voltage Input:
220 VAC (50Hz), 75W Max
Power consumption:
75 W max
Interface:
USB
Communication:
Modbus RTU, over RS232
Optical Head mounting:
M6 for rod and/or tripod (custom available)
Documentation

Light Stimulator for Sun Sensors is an Optical Ground Support Equipment (OGSE) based on a controlled and stable light source to stimulate optical sensors, designed to work under TVAC.

LS3 operates without touching the sensor or the platform where the device to be stimulated is placed. It includes a 19” controller and up to 3 optical heads per unit, with an interface for PC to program the testing operations.

LS3 - Light Simulator

SOLAR MEMS TECHNOLOGIES
Description

Light Stimulator for Sun Sensors is an Optical Ground Support Equipment (OGSE) based on a controlled and stable light source to stimulate optical sensors, designed to work under TVAC.

LS3 operates without touching the sensor or the platform where the device to be stimulated is placed. It includes a 19” controller and up to 3 optical heads per unit, with an interface for PC to program the testing operations.

Current Stock:
Adding to request… The item has been added
Add this to a request to access pricing information and additional technical data. After submission, get a response within 3 business days.
Additional Information
Lead Time:
12 weeks
Beam Size:
25 mm diameter
Beam Homogeneity:
> 90%
Light Collumation:
< 10 degree
Lightspectrum:
450 - 1100 nm
Optical head temperature range:
-50C to 100C (no vacuum)
Optical head temperature range:
-40C to 80C (vacuum)
Voltage Input:
220 VAC (50Hz), 75W Max
Power consumption:
75 W max
Interface:
USB
Communication:
Modbus RTU, over RS232
Optical Head mounting:
M6 for rod and/or tripod (custom available)
Documentation

Light Stimulator for Sun Sensors is an Optical Ground Support Equipment (OGSE) based on a controlled and stable light source to stimulate optical sensors, designed to work under TVAC.

LS3 operates without touching the sensor or the platform where the device to be stimulated is placed. It includes a 19” controller and up to 3 optical heads per unit, with an interface for PC to program the testing operations.
