EnduroSat 6U CubeSat Platform - Orbital Transports SmallSat Catalog

6U CubeSat Platform - Endurosat

Our 6U CubeSat Platform is a fully integrated microsatellite capable of supporting up-to 4U (7.8 kg) payloads. Available with Attitude Determination and Control System (ADCS) with pointing accuracy as high as 0.01 degrees and complete payload integration, this is the most advanced satellite system in its class.

Included

  • Packed in a protective case
  • Technical information (Datasheet)
  • 10 hours of engineering support
  • Full warranty

Qualification

During the space qualification campaign, EnduroSat CubeSats underwent high level of functional tests to demonstrate the integrity of the system. All modules were performing at their nominal level. The tests were performed following the strict specifications of the ESA ECSS-E-ST-10-03C and NASA GEVS: GSFC-STD-7000A standards.

Specifications
Available Payload volume:
97 x 197 x 223 mm
Available Mass:
7.2-7.8 kg (configuration dependent)
Available Power:
10-30 W (orbit and mission dependent)
Power Buses Voltages:
3.3 V, 5 V, Customizable 6-12 V, BCR and battery raw
Data rate in the air:
up to 150 Mbps
Attitude Control:
< 0.1-1 degrees accuracy (optional up to 0.01)
Lifetime:
1 – 5 years (orbit dependent)
